LG PuriCare™ Objet Collection Water Purifier, C.Grey

1. Press and hold the Outlet Sterilize button at the top of the purifier for 3 seconds.
2. Place a container with a capacity of 300ml or greater below the water outlet.
3. When the container larger than 300ml has been prepared and placed, press the Dispense Water button. The sterilization process will take about 10 minutes.
*Hot water will be dispensed about 7 minutes later. Please ensure that this is inaccessible by children.
4. Once the sterilization of the water outlet is complete, please discard the hot water dispensed into the container.

Changing through ThinQ app

1. In the LG ThinQ App, press the water purifier icon.

2. Select the '>' icon in the High Temperature Sterilization window, or select 'Schedule high temperature water pipe sterilization' under Settings.

3. In Schedule Sterilization, press the '>' button.

4. Set the desired schedule time and press the Save button.

How to change using product interface

1. Press and hold the Internal Sterilize + Outlet Sterilize buttons for 3 seconds.

2. To change the date, press the 'Outlet Sterilize button. The date will change every time the button is pressed.

3. To change the time, press the 'Internal Sterilize' button. The time will change every time the button is pressed.

4. Set the desired schedule time and press and hold the 'Dispense Water' button for 3 seconds.

If the valve where the source water is supplied or the dispense valve of the faucet is closed, the water pipe sterilization and water outlet sterilization features will not work. Please open the source water valve or the dispense valve.

• Step 1: Pull out the draining tray to remove it from the product.
• Step 2: Push the moving tap to the end of left or right and open the filter cover.
• Step 3: Grab the filter and lift it 90 degrees, and then turn it counterclockwise to separate it.
• Step 4: Insert the filter and turn it clockwise.
• Step 5: Place the filter cover on again. The filter cleaning process takes about 7 minutes.
• Step 6: When the filter cleaning is complete, press and hold the Cold Water button for more than 3 seconds to reset the filter usage count.

If you close the source water valve during filter replacement, the filter cleaning will not work as the source water will not be supplied.

Do not close the source water valve, and leave it open while changing the filter. Close the filter cover to proceed with the filter cleaning process.

1. In the LG ThinQ App, press the water purifier icon.

2. Press the 'ⓘ' icon at the top-right corner of the screen, and press the Settings window.

3. In the Settings, select the product sound setting '>' icon.

4. When 'Use' is selected, the 'Button Sound' and 'Water Dispense Voice' can be set.

5. Select the '>' icon of Control Volume to adjust the volume.

Even when muted, the voice instructions will continue to be provided during water outlet sterilization, water pipe sterilization, and filter change for safety reasons.

If you have separated the draining tray while the tray is rotated, the filter cover handle hole may also be rotated, preventing easy opening of the filter cover. Please check the joining section (locking hole) of the draining tray before connecting the draining tray from the front. Separate it again and open the filter cover.
